ZCN028 Magnetic Pole Coil Slanting Winder, No Incrassation

Technical Specifications:

1、Little incrassation without burnishing, according to process demand

2、Max. section of winding coil: 4×70mm², 6×50mm², 10×40mm², pressure 110T, min. thickness 1.5mm

3、Max. weight of magnetic coil after winding 1.1T

4、Single arm lift weight 1.5T

5、Oil pressure: 250MPa

6、Coil thickness after winding (inside), thickness incrassation <0.08mm

7、Max. frame outside dimension after winding: 700×2200mm² (the size and shape of coil winding is independent of power & oil pressure)

8、Motor power (winding motor): 7.5kW

9、Frequency inverter for speed adjustment
